The Wagner Puma 21-110 is a high-pressure piston pump designed for industrial coating applications, particularly in AirCoat systems. Its robust stainless steel construction ensures durability and reliable performance, making it suitable for operations requiring multiple spray guns, such as flatbed machines.
Puma 21-110
$8,462.20
High-Pressure Piston Pumps
Shipping quote: Shipping for this item will be quoted separately. We will contact you with the shipping cost after you place your order.
- Pressure Ratio: 21:1
- Maximum Operating Pressure: 168 bar (2,436 PSI)
- Maximum Flow Rate: Up to 6.6 liters per minute (1.74 GPM)
- Multiplication ratio- 21:1
- Operating pressure- 168 bar, 2437 PSI
- Volumetric flow per double stroke- 110 cm³/DS, 6,71 in³/DH
- Volumetric flow per 60 double strokes- 6.6 l/min
- Max. stroke rate- 60 DS/min
- Material inlet- M: M 36×2
- Material outlet- M: M 24×1,5
- Air inlet pressure- 2,5-8,0 bar, 36-116 PSI
- Sound level at 6 bar air pressure- 74 dB(A)
- Material temperature- 5 – 80 °C, 41 – 176 °F
- Ambient temperature- 5-60 °C, 41-140 °F
- Material- pH 3.5-9 pH
- Max. material pressure at pump inlet- 20 bar, 290 PSI
- Allowable inclination- ±10 °
- Weight- 28,0 kg, 61.7 lb
| Specification | Value |
|---|---|
| Puma 21-110 PE/TG (Part No. 2329517) | Features polyethylene (PE) piston seals and tungsten carbide (TG) seats, offering enhanced durability and compatibility with abrasive materials. |
| Puma 21-110 PE/T (Part No. 2330614) | Equipped with polyethylene (PE) piston seals and standard (T) seats, providing reliable sealing and extended service life. |
Included Components
| Specification | Value |
|---|---|
| Pump Unit | Puma 21-110 PE/TG or PE/T |
| Mounting Options | Available in wall mount or cart mount configurations, depending on operational requirements. |
| Regulator | AirCoat Regulator IceBreaker |
| Suction Hose Assembly | Suction hose DN16-SSt, complete |
| Spray Gun | GM 4700 AC with Air Cap and Tip |
| Hose Set | Twin Hose Set – 25 ft |
| Throat Seal Lubricant | 250 mL bottle |
