Binks Gemini II 1″ Stainless Steel Diaphragm Pump

Precision-built equipment for professional finishing.

Proudly Canadian
🔍
Binks Gemini II 1" Stainless Steel Diaphragm Pump

Binks Gemini II 1″ Stainless Steel Diaphragm Pump

Price range: $5,592.65 through $5,840.60

Binks Gemini II 1″ 316 stainless steel air-operated diaphragm pump for spraying, transferring and circulating waterborne and solvent-based coatings. Up to 45 GPM (170 L/min), 125 psi max, 38% more delivery per cycle than previous Binks models. Choose 1″ NPT (41-818822) or 1″ BSP (41-818823) ports.

SKU: Parent-Binks 1" SS Category: Brand:

The Binks Gemini II 1″ Stainless Steel Diaphragm Pump is part of Binks’ premier Gemini II line of diaphragm pumps, built for spraying, transferring and circulating a wide range of coatings and viscosities. It is used in wood finishing, general metal fabrication and adhesive applications.

The 1″ Gemini II delivers up to 38% more material per cycle than previous Binks models, with lower pulsation for a smoother, more consistent spray. The stainless steel construction makes it compatible with both waterborne and solvent-based materials.

Rated for up to 45 GPM (170 L/min) at a maximum operating pressure of 125 psi (8.6 bar), with a no-lube, no-stall air valve and solids handling up to 6 mm.

Available in two part numbers: 41-818822 with 1″ NPT ports and 41-818823 with 1″ BSP tapered ports.

  • Higher Output:Up to 45 GPM (170 L/min) with 0.42 L per stroke, 38% more delivery per cycle than previous Binks 1″ models.
  • Lower Pulsation:Smoother fluid delivery than the Gemini I series for a more even finish.
  • 316 Stainless Steel Wet End:Stainless steel body, check balls and seats for waterborne and solvent-based coatings, including adhesives, catalyzed varnishes, paints, resins, stains and solvents.
  • No-Lube, No-Stall Air Valve:Reliable cycling without air-line lubrication.
  • Handles Solids:Passes particles up to 6 mm (0.25″).
  • NPT or BSP Ports:Choose 41-818822 with 1″ NPT ports or 41-818823 with 1″ BSP tapered ports.
  • Easy Servicing:Dedicated air motor, diaphragm and ball & seat repair kits keep downtime short.
SpecificationValue
SeriesBinks Gemini II (Model S1F Metallic)
Pump TypeAir-operated double diaphragm (AODD)
Body Material316 stainless steel (ASTM A743 CF-8M)
Suction / Discharge Ports41-818822: 1″ NPT (internal)
41-818823: 1″ BSP tapered (internal)
Air Inlet1/2″ NPT
Exhaust Port1″ NPT (optional muffler or piped exhaust)
Capacity0 to 45 GPM (0 to 170 L/min)
Displacement per Stroke0.11 gal (0.42 L)
Maximum Operating Pressure125 psi (8.6 bar)
Maximum Head125 psi / 289 ft of water (8.6 kg/cm² / 86 m)
Solids HandlingUp to 0.25″ (6 mm)
Air Distribution ValveNo-lube, no-stall design
DiaphragmsSynthesis one-piece
Check Balls & Seats316 stainless steel
Manifold O-ringsPTFE; FEP-encapsulated FKM O-rings on check valve seats
MufflerMetal (530-033-000)
Ambient Temperature Range-20°C to +40°C
Process Temperature Range-20°C to +100°C (category 2 equipment)
Shipping Weight43 lb (20 kg)
Compatible MaterialsWaterborne and solvent-based adhesives, catalyzed varnishes, paints, resins, stains, solvents
ComplianceCE, ATEX (when properly grounded)
Service Kits41-718855 Air Motor Repair Kit
41-718856 Diaphragm Kit
41-718857 Ball and Seat Kit
Service Manual77-2994
Gemini II Diaphragm Pumps Brochure (03-542-01)Gemini II Pump Service Manual 77-2994 (English)Gemini II Pump Service Manual 77-2994 (French)Gemini II Wall Mount Manual 77-3031Gemini Pump Air Control Assembly 77-3033
