Double diaphragm pump for airspray applications.
Double diaphragm pump for airspray applications. Cost-effective entry level model without material pressure regulator. Nevertheless it offers low-pulsation thanks to large material filter. For pressures up to 8 bar and one gun.
Order information: Select material hose package and airspray gun to complete the spraypack.
| Specification | Value |
|---|---|
| Multiplication ratio | 1:1 |
| Material pressure | 8 bar |
| Volumetric flow per double stroke | 62 cm3/DS |
| Volumetric flow per free flow | 28 l/min |
| Material inlet | G 1/2‘‘ – F |
| Material outlet | G 1/4‘‘ – M |
| Air inlet pressure range | 1 bar – 8 bar |
| Compressed air connection | M – G 1/4‘‘ |
| Sound level at 6 bar air pressure | 73 dB(A) |
| Material temperature range | 4 °C – 90 °C |
| Ambient temperature range | 4 °C – 40 °C |
| Weight | 7.9 kg |
| Material-wetted parts | Aluminum, PE, Stainless steel |
