Source Pre-Filter

$867.29

REMOTE

SKU: 9350-03 Category: Tag:

Where air quality is especially low, this free-standing or wall-mounted particulate assembly helps extend the life of the filter panel’s disposable filters by removing liquids and contaminants down to 5 microns. It is equipped with an adjustable regulator pressure gauge and meets NIOSH requirements for point-of-attachment.

  • Stand:Powder coated steel.
  • Relief valve:Brass, spring loaded (External)
  • Max Temperature:150° F (65.5° C)
  • Maximum pressure:250 psi (17.2 bar)
  • Flow Capacity:165 CFM (280.33 m3/hr)
  • Fittings:½” (1.27 cm) Quick-Connect Hansen.
  • Manifold:Zinc.
  • Adjusting knob:Acetal.
  • Body Cap:ABS.
  • Valve:Balanced Valve Design, Brass/Nitrile.
  • Diaphragm:Spring loaded, Nitrile/Zinc.
  • Pressure gauge:Analog, 0-300 psi (0-20.69 bar), 2” (5.08 cm) diameter.
  • Bowl:Zinc, with a Polycarbonate sight gauge.
  • Element retainer:Acetal.
  • Useful Retention:2.87 oz. (81.36 g)
  • Seal:Nitrile.
  • Standard Filtration:5 Micron.
  • Element Type:Particulate.
  • Material:Sintered Polyethylene.
  • Drain:Automatic mechanical with float.
9350 03 Source Pre FilterPDF
