Binks Trophy Touch-UP Pressure Feed Spray Gun 1465

Precision-built equipment for professional finishing.

Proudly Canadian
🔍
Binks Trophy Touch-UP Pressure Feed Spray Gun 1465

Binks Trophy Touch-UP Pressure Feed Spray Gun 1465

$990.35

START WITH CONFIDENCE. FINISH WITH A TROPHY.

Shipping quote: Shipping for this item will be quoted separately. We will contact you with the shipping cost after you place your order.
SKU: Parent-Binks Trophy Touch-UP Pressure Feed Spray Gun 1465 Category: Tag: Brand:

The Binks Trophy Touch-Up Pressure Feed Spray Gun (Model 1465) is a high-performance spot repair gun designed for precision finishing in automotive, woodworking, marine, and industrial applications.
This compact gun combines the legendary Binks build quality with advanced atomization, lightweight handling, and precise fluid control.

  • Pressure Feed Design: Ensures consistent material flow for precise touch-ups.
  • Lightweight & Ergonomic: Comfortable handling (~300-350 g) for extended use.
  • Stainless Steel Wetted Parts: Durable fluid passages and needle compatible with low- to medium-viscosity coatings.
  • Adjustable Nozzles: Typically 0.8 mm, 1.4 mm depending on configuration for fine or detailed work.
  • Robust Construction: Anodized aluminum body for corrosion resistance and long service life.
  • Versatile Applications: Automotive, woodworking, furniture repair, and light industrial finishes.
SpecificationValue
SeriesBinks Trophy
Spray TechnologiesHVLP (blue), LVMP / Trans-Tech (green), Conventional (brown)
Air ValveNo-kick design
Gun TypeManual air spray gun, Pressure feed, touch-up
Configurations1465-10HV-C1S: 1465-10HV-C1S – Nozzle Size: 1.0mm, Air Cap: C1S
1465-10LV-B1S: 1465-10LV-B1S – Nozzle Size: 1.0mm, Air Cap: B1S
1465-12HV-C1S: 1465-12HV-C1S – Nozzle Size: 1.2mm, Air Cap: C1S
1465-12LV-B1S: 1465-12LV-B1S – Nozzle Size: 1.2mm, Air Cap: B1S
1465-14HV-C1S: 1465-14HV-C1S – Nozzle Size: 1.4mm, Air Cap: C1S
1465-14LV-B1S: 1465-14LV-B1S – Nozzle Size: 1.4mm, Air Cap: B1S
Service Manual77-3042
Trophy Manual Guns Brochure 03-473-01Trophy Touch-Up Gun Manual 77-3042Trophy Air Valve Service Kit 77-3029
