Binks PRO Lite E Conventional Pressure Spray Gun, C67 Cap, 1.8 mm Carbide – PROLT-EC67-18C

Precision-built equipment for professional finishing.

Proudly Canadian

Binks PRO Lite E Conventional Pressure Spray Gun, C67 Cap, 1.8 mm Carbide – PROLT-EC67-18C

$1,724.05

Heavy-duty pressure feed spray gun for abrasive water-based ceramic and vitreous enamel coatings.

Shipping quote: Shipping for this item will be quoted separately. We will contact you with the shipping cost after you place your order.
SKU: PROLT-EC67-18C Category: Brand:

The Binks (DeVilbiss) PRO Lite E is an enhanced version of the PRO Lite pressure feed spray gun, built for heavy-duty finishing with abrasive ceramic glazes and vitreous enamel. It is designed for continuous, reliable work at high fluid flow, up to 3.5 L/min with heavy-weight ceramic glaze. It is for water-based ceramic and enamel materials only.

The gun has a drop-forged aluminum body with a QuickClean coating, a stainless steel lined fluid passageway so only stainless steel touches the material, and abrasion-resistant needle packing to stand up to abrasive coatings. It is used in ceramics, sanitaryware, appliance and enamelling plants.

PROLT-EC67-18C is supplied with the C67 conventional air cap, designed for a wide spray fan and high fluid flow, and a 1.8 mm tungsten carbide fluid tip and needle for the longest wear life with abrasive materials.

  • Built for abrasive coatings:Designed for continuous use with ceramic glazes and vitreous enamel.
  • Tungsten carbide tip and needle:1.8 mm carbide fluid tip and needle for maximum wear resistance.
  • High fluid flow:Enlarged fluid passages handle up to 3.5 L/min of heavy ceramic glaze.
  • Wide fan C67 air cap:Conventional air cap designed for a wide spray fan at high fluid flow.
  • Stainless steel fluid path:Lined passageway so only stainless steel contacts the material.
  • Abrasion-resistant packing:Needle packing made to resist abrasive coatings.
  • QuickClean body:Drop-forged aluminum with QuickClean coating for faster cleaning and durability.
SpecificationValue
Brand / seriesBinks (DeVilbiss) PRO Lite E
Part numberPROLT-EC67-18C
Feed typePressure feed
AtomizationConventional
Air capC67 conventional (PROC-120-C67-K)
C67 air cap performance425 L/min (15.0 cfm) at 3.0 bar (45 psi), max fan 500 mm
Fluid tip and needle1.8 mm tungsten carbide
Max fluid flowUp to 3.5 L/min (heavy ceramic glaze)
Air inlet1/4″ Universal thread
Fluid inlet3/8″ Universal thread (BSP and NPS)
Max air inlet pressure12 bar (174 psi)
Max fluid inlet pressure15 bar (218 psi)
Max ambient operating temperature40 °C
Gun bodyDrop-forged aluminum, QuickClean coating
Fluid passagewayStainless steel lined
Needle packingAbrasion-resistant
Suitable materialsWater-based ceramic and vitreous enamel only
