PRODUCTS > WAGNER GA 4000AC AirCoat Automatic Guns
4000AC thumbnail

WAGNER GA 4000AC AirCoat Automatic Guns

Perfect finishing for high quality surfaces

Overview

The WAGNER GA 4000AC is a state-of-the-art automatic AirCoat spray gun designed for high-precision industrial applications. Combining the benefits of airless and air-assisted atomization, it delivers superior finish quality with high transfer efficiency, making it ideal for automated lacquer spraying systems.​



Variants and Accessories

  • GA 4000ACIC: Internal control version for precise spray pattern adjustments.
  • GA 4000ACEC: External control version allowing remote adjustments.
  • Air Caps: Available in Red (low viscosity materials), Blue (high viscosity materials), and Bronze (general-purpose).
  • Nozzles: Wide range of flat (ACF) and round (ACR) spray nozzles for various applications.
  • Base Plates: Multiple configurations available for diverse installation requirements.​

Order Here
TECHNICAL SPECIFICATIONS:
- Max. Material Pressure: 250 bar (3626 PSI)- Max. Air Inlet Pressure: 8 bar (116 PSI)- Max. Material Temperature: 80°C (176°F)- Operating Temperature Range: 5–40°C (41–104°F)Weight: 0.7 kg (1.5 lb)- Dimensions: Length 129 mm (5.1 in), Width 47 mm (1.9 in), Height 60 mm (2.4 in)- Sound Level: 82 dB(A)- Fluid Inlet: G 1/4"- Compressed Air Connection: 8 mm?
PART NUMBER:
- Gun GA 4000ACIC:2312132- Gun GA 4000ACEC: 2312145
GA4000AC_10-2020_EN.pdf GA4000ACIC_ENG.pdf
