Overview
The Wagner Jaguar 75-150 is a high-pressure piston pump engineered for demanding industrial applications, particularly in heavy corrosion protection. Its robust stainless steel construction ensures durability and consistent performance.
Technical Specifications- Pressure Ratio: 75:1
- Maximum Operating Pressure: 530 bar (7,687 PSI)
- Volumetric Flow per Double Stroke: 150 cm³ (9.15 in³)
- Maximum Flow Rate: 9 liters per minute
- Material Inlet: F–G 1 1/2''
- Material Outlet: M–M 24x1.5
- Air Inlet Pressure: 2.5–7.1 bar (36–103 PSI)
- Sound Level at 6 bar Air Pressure: 81 dB(A)
- Material Temperature Range: 5–80 °C (41–176 °F)
- Ambient Temperature Range: 5–60 °C (41–140 °F)
- Material pH Range: 3.5–9
- Maximum Material Pressure at Pump Inlet: 20 bar (290 PSI)
- Allowable Inclination: ±10°
- Weight: 53 kg (116.9 lbs)
- Materials in Contact with the Product:
- Tungsten Carbide
- Stainless Steel
- Hard Chrome
- PTFE
Included Items:Pump with Air Pressure Regulator
250 cm³ Separating Agent Bottle
Operating Manual
CE Declaration of ConformityProduct Variants and Part Numbers:Piston Pump Jaguar 75-150-PC PE/TG: Part No. 2339845
SP Jaguar 75-150 Trolley: Part No. 2339867
SP Jaguar 75-150 Trolley without High-Pressure Filter: Part No. 2347528
SP Jaguar 75-150 GM 1-530 Trolley: Part No. 2352765
SP Jaguar 75-150 GM 1-530 Trolley without High-Pressure Filter: Part No. 2352857Service Sets:Service Set Fluid Section 70/150 cm³ PE+TG: Part No. 368990
Service Kit Air Motor 9": Part No. 369987
