Overview
Electrostatic manual gun for AirCoat applications with low-conductive solvent-based lacquers. With integrated high-voltage cascade. Additionally required: Control unit VM 500 or VM 5000.
Key Feature- High efficiency- The GM 5000 automatic guns offer a soft and homogeneous spray jet for high coating quality and outstanding application efficiency. Typically, 30-50% of material can be saved compared to conventional coating processes.
- Reliable- Innovative nozzles and air caps, specially developed for the perfect combination of optimum droplet size with electrostatic charge for particularly high coating performance and quality.
- Low maintenance- The replaceable hook significantly reduces service costs.
- Strong Performance- The material is ionized by the flexible and durable electrode directly at the material nozzle. Even under extreme loads it keeps its shape and ensures a constant material charge and good handling.
- Safe working- The GM 5000 gun series complies with CE and Atex zone 1 standards. For maximum safety of the painter, the grounding of the gun is monitored by the control unit. It automatically disconnects the high voltage as soon as the grounding is interrupted.
Technical dataPart Number: 2309871 (no air cap or tip)
Application area: Metal coating, Wood coating
Application technique: AirCoat, Electrostatic solvent-based
Processable materials: Solvent-borne, Abrasive, shear sensitive, sensitive to moisture
Material wetted parts: Stainless steel 1.4305
Weight: 710 g
Compressed air connection: M G 1/4''
Max. material pressure: 250 bar
Max. sound level: 73 dB(A)
Operating temperature: 5-40 °C
