Overview
Electrostatic Technology The WAGNER electrostatic guns are highly economical coating systems, offering decisive advantages in many areas of the industry.
Key Feature- Excellent coating results - The GM 5000 automatic guns offer a soft and homogeneous spray jet for high coating quality and outstanding application efficiency. Typically, 30-50% of material can be saved compared to conventional coating processes.
- Flexible applications - Harsh environment, intensive use, different spray materials and much more: that's what the GM 5000 series was designed for. The exchangeable hook ensures low service costs.
- Safe working - The GM 5000 gun series complies with CE and Atex zone 1 standards. For maximum safety of the painter, the grounding of the gun is monitored by the control unit. It automatically disconnects the high voltage as soon as the grounding is interrupted.
- High surface quality - Innovative nozzles and air caps, specially developed for the perfect combination of optimum droplet size with electrostatic charge for particularly high coating performance and quality.
- Strong Performance - The material is ionized by the extremely flexible and durable electrode directly at the material nozzle. Even under extreme loads it keeps its shape and ensures a constant material charge and good handling.
Technical dataPart Number- 2309870 (no air cap or tip)
Application area- Metal coating, Plastic coating, Wood coating
Application technique- Airspray, Electrostatic solvent-based
Processable materials- Abrasive, shear sensitive, sensitive to moisture
Material wetted parts- Stainless steel, Tungsten carbide
Weight- 630 g
Compressed air connection- M G 1/4''
Max. material pressure- 8 bar
Material conductivity- 18.5-123 MΩ.cm
Material conductivity LowR- 6.2-123 MΩ.cm
Operating temperature- 5-40 °C
